Printing Parameters
| Description | Data | Desciption | Data |
| Nozzle Temperature | 190—230℃ | Nozzle Size | 0.2,0.4,0.6,0.8mm |
| Printing Platform Material | - | Printing Platform Surface Treatment | Add glue according to material |
| Bottom Value Sparation Distance | 0.4-0.6 | Withdrawal Distance | 5mm |
| Environment Temperature | Room temperature | Withdrawal Speed | 50mm/s |
| Recommended Support Material | - | Drying Temperature | 50℃ |
| Printing Speed | 40--300 mm/s | Cooling Fan | 100% |
| - | |||
Physical Properties
| Properties | Testing method | Value |
| Density | ISO 1183 | 1.31g/cm3 |
| Melt Flow Index | 210℃,2.16kg 39.4±3.2g/min | |
| 20g/10min |
Thermal Performance
| Properties | Testing Method | Value | |
| Glass Transsition | DSC, 10℃/min | 61℃ | |
| Melting Temperature | DSC, 10℃/min | 163℃ | |
| Decomposition Temperature | / | ≥374℃ | |
| Vicat Softening Temperature | ISO 306, GB/T 1040 | 63℃ | |
| Heat Distortion Temperature | ISO75 | 0.45Mpa/58℃, 1.80Mpa/52℃ | |
Mechanical Performance
| Printing Direction | Testing Standard | Data |
| Tensile Strength | ISO527, GB/T 1040 | 32Mpa |
| Elongation at break | ISO527, GB/T 1040 | 6.8% |
| Flexural Strength | ISO178, GB/T 9341 | 55Mpa |
| Flexural Modulus | ISO178, GB/T 9341 | 2456Mpa |
| Impact Strength with Notched | ISO179, GB/T 1043 | 6.73KJ/㎡ |
| Impact Strength without Notched | ISO179, GB/T 1043 | 19.2KJ/㎡ |
