Unleash your creativity with our vibrant color PLA filament for 3D printers, designed to make your 3D prints stand out in the European and American markets. In a world where visual appeal matters, these filaments offer a rainbow of colors that can transform any 3D design into a work of art.
From bold primary colors to soft pastels and eye - catching metallics, our range of vibrant color filaments caters to all artistic tastes and project needs. Whether you're creating decorative items for home decor, designing promotional products for businesses, or crafting unique toys for children, these filaments add a touch of vibrancy and charm. The high - quality pigments used in the filaments ensure long - lasting colorfastness, so your prints will retain their vivid hues over time.
Not only do these filaments offer stunning colors, but they also maintain excellent printability. They flow smoothly through the 3D printer's extruder, allowing for detailed and accurate prints. The filaments have a low shrinkage rate, ensuring that the final product matches the intended design as closely as possible. With our vibrant color PLA filament, you can turn your 3D printing ideas into reality with style and flair.
Unleash your creativity with our vibrant color PLA filament for 3D printers, designed to make your 3D prints stand out in the European and American markets. In a world where visual appeal matters, these filaments offer a rainbow of colors that can transform any 3D design into a work of art.
From bold primary colors to soft pastels and eye - catching metallics, our range of vibrant color filaments caters to all artistic tastes and project needs. Whether you're creating decorative items for home decor, designing promotional products for businesses, or crafting unique toys for children, these filaments add a touch of vibrancy and charm. The high - quality pigments used in the filaments ensure long - lasting colorfastness, so your prints will retain their vivid hues over time.
Not only do these filaments offer stunning colors, but they also maintain excellent printability. They flow smoothly through the 3D printer's extruder, allowing for detailed and accurate prints. The filaments have a low shrinkage rate, ensuring that the final product matches the intended design as closely as possible. With our vibrant color PLA filament, you can turn your 3D printing ideas into reality with style and flair.
Mechanical Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Tensile Strength | ISO 527 | 50mm/min | 63.33 | 34.74±4 | 30.34±4 | MPa |
Elongation at Break | ISO 527 | 50mm/min | 3.31 | 5.18±1 | 1.6±0.2 | % |
Tensile Modulus | ISO 527 | 50mm/min | 2408.34 | 2200.4±100 | 2057.5±100 | MPa |
Flexural Strength | ISO 178 | 2mm/min | 91.04 | 58.36±4 | 44.31±4 | MPa |
Flexural Modulus | ISO 178 | 2mm/min | 3646.67 | 2326.67±100 | 2057.5±100 | MPa |
Charpy Impact Strength | ISO 179 | 23℃ | 24.73 | 18±2 | 7.54±1 | KJ/㎡ |
Izod Impact Strength | ISO 180 | 23℃ | 18.1 | 12.66±2 | 6.44±1 | KJ/㎡ |
Physical Properties
Property | Testing Method | Testing Condition | Typical Value | Unit |
Density | ISO 1183 | Immersion | 1.17 | g/cm3 |
Melt Flow index(MFR) | ISO 1133 | 210℃/2.16kg | 2-7 | g/10 min |
Moisture Absorption
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing Typical Value | Unit |
Moisture Absorption | ISO 62 | 50%RH*23℃ | 0.5 | 0.6 | % |
Chemical Properties
Property | Testing Result |
Weak Acid Resistance | Not Resistant |
Strong Acid Resistance | Not Resistant |
Weak Base Resistance | Not Resistant |
Strong Base Resistance | Not Resistant |
Organic Solution Resistance | Not Resistant |
Thermal Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Glass Transition Temperature | DSC | 10℃/min | 65.5 | ℃ | ||
Crystallization Temperature | DSC | 10℃/min | 107.7 | ℃ | ||
Melting Point | DSC | 10℃/min | 147.8 | ℃ | ||
Distortion Temperature | TGA | 20℃/min | N/A | ℃ | ||
Heat Distortion Temperature | ISO 75 | 0.45MPa | 57.6 | 55.3 | 56.6 | ℃ |
Heat Distortion Temperature | ISO 75 | 1.8MPa | 56.5 | 54.8 | 52.4 | ℃ |
Vicat Softening Temperature | ISO 306 | 50℃/10N | 61.6 | 59.6 | 60 | ℃ |
Recommended 3D Printing Parameters
*Based on 0.4 mm nozzle. Printing conditions may vary with different nozzle diameters
Printing Temperature | 210-230(℃) |
Bed Temperature | 50-60(℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 0-10% |
Printing Speed | 30 — 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
3DPrinting Actual Parameters
*All specimens must be left at room temperature for 24 hours before testing. The parameters are based on the Bambulab P1S 3D printer.
Printing Temperature | 220(℃) |
Bed Temperature | 55(℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 10% |
Printing Speed | 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
Mechanical Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Tensile Strength | ISO 527 | 50mm/min | 63.33 | 34.74±4 | 30.34±4 | MPa |
Elongation at Break | ISO 527 | 50mm/min | 3.31 | 5.18±1 | 1.6±0.2 | % |
Tensile Modulus | ISO 527 | 50mm/min | 2408.34 | 2200.4±100 | 2057.5±100 | MPa |
Flexural Strength | ISO 178 | 2mm/min | 91.04 | 58.36±4 | 44.31±4 | MPa |
Flexural Modulus | ISO 178 | 2mm/min | 3646.67 | 2326.67±100 | 2057.5±100 | MPa |
Charpy Impact Strength | ISO 179 | 23℃ | 24.73 | 18±2 | 7.54±1 | KJ/㎡ |
Izod Impact Strength | ISO 180 | 23℃ | 18.1 | 12.66±2 | 6.44±1 | KJ/㎡ |
Physical Properties
Property | Testing Method | Testing Condition | Typical Value | Unit |
Density | ISO 1183 | Immersion | 1.17 | g/cm3 |
Melt Flow index(MFR) | ISO 1133 | 210℃/2.16kg | 2-7 | g/10 min |
Moisture Absorption
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing Typical Value | Unit |
Moisture Absorption | ISO 62 | 50%RH*23℃ | 0.5 | 0.6 | % |
Chemical Properties
Property | Testing Result |
Weak Acid Resistance | Not Resistant |
Strong Acid Resistance | Not Resistant |
Weak Base Resistance | Not Resistant |
Strong Base Resistance | Not Resistant |
Organic Solution Resistance | Not Resistant |
Thermal Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Glass Transition Temperature | DSC | 10℃/min | 65.5 | ℃ | ||
Crystallization Temperature | DSC | 10℃/min | 107.7 | ℃ | ||
Melting Point | DSC | 10℃/min | 147.8 | ℃ | ||
Distortion Temperature | TGA | 20℃/min | N/A | ℃ | ||
Heat Distortion Temperature | ISO 75 | 0.45MPa | 57.6 | 55.3 | 56.6 | ℃ |
Heat Distortion Temperature | ISO 75 | 1.8MPa | 56.5 | 54.8 | 52.4 | ℃ |
Vicat Softening Temperature | ISO 306 | 50℃/10N | 61.6 | 59.6 | 60 | ℃ |
Recommended 3D Printing Parameters
*Based on 0.4 mm nozzle. Printing conditions may vary with different nozzle diameters
Printing Temperature | 210-230(℃) |
Bed Temperature | 50-60(℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 0-10% |
Printing Speed | 30 — 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
3DPrinting Actual Parameters
*All specimens must be left at room temperature for 24 hours before testing. The parameters are based on the Bambulab P1S 3D printer.
Printing Temperature | 220(℃) |
Bed Temperature | 55(℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 10% |
Printing Speed | 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
