Printing Parameters
Nozzle temperature:190—230℃
Heated bed temperature:40—60℃
Nozzle diameter:≥0.4mm
Printing platform: Add adhesive according to materials
Printing speed:40—300mm/s
Cooling fan: On
Suitable for all FDM 3D Printers / 3D Printing Machines
Physical Properties
Properties | Testing Method | Value |
Density | ISO 1183-1 | 1.21 g/cm3 |
Melt Flow Index | ISO 1133 | 10g/10min |
Thermal Performance
Properties | Testing Method | Value |
Glass Transition | ISO 11357 | 60℃ |
Melting Temperature | ISO 11357 | 155℃ |
Decomposition Temperature | / | 377℃ |
Vicat Softening Temperature | ISO 306 | 59℃ |
Heat Distortion Temperature | ISO 72 | 0.45Mpa/56℃ 1.80Mpa/53.8℃ |
Mechanical Performance
Printing Direction | Testing Standard | Data |
Tensile Strength | ISO 527 | 53Mpa |
Elongation at break | ISO 527 | 2.3% |
Flexural Strength | ISO 178 | 74Mpa |
Flexural Modulus | ISO 178 | 2650Mpa |
Impact Strength with Notched | ISO 179 | 11KJ/㎡ |
Charpy Impact Strength without Notched | ISO 179 | 15.86KJ/㎡ |
