Color: | |
---|---|
Availability: | |
Mechanical Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Tensile Strength | ISO 527 | 50mm/min | 52.5 | 45.2 ±4 | 37.6 ±4 | MPa |
Elongation at Break | ISO 527 | 50mm/min | 66.7 | 11.4 ±1.8 | 1.7 ± 0.5 | % |
Tensile Modulus | ISO 527 | 50mm/min | 1668 | 1720 ±100 | 1711 ± 100 | MPa |
Flexural Strength | ISO 178 | 2mm/min | 76.2 | 68.7 ± 6.5 | 61.8 ±6.5 | MPa |
Flexural Modulus | ISO 178 | 2mm/min | 2280 | 1967 ±100 | 1901 ± 100 | MPa |
Charpy Impact Strength | ISO 179 | 23℃ | NB | 25 ± 3.5 | 10.5 ± 2 | KJ/㎡; |
Izod Impact Strength | ISO 180 | 23℃ | NB | 29.8 ±3.5 | 7.7 ± 2 | KJ/㎡; |
Physical Properties
Property | Testing Method | Testing Condition | Typical Value | Unit |
Density | ISO 1183 | Immersion | 1.26 | g/cm3 |
Melt Flow index(MFR) | ISO 1133 | 240℃ 2.16kg | 10.0 | g/10 min |
Moisture Absorption
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing Typical Value | Unit |
Moisture Absorption | ISO 62 | 50%RH*23℃ | 0.06 | 0.05 | % |
Chemical Properties
Property | Testing Result |
Weak Acid Resistance | Not Resistant |
Strong Acid Resistance | Not Resistant |
Weak Base Resistance | Not Resistant |
Strong Base Resistance | Not Resistant |
Organic Solution Resistance | Not Resistant |
Thermal Properties
Property | Testing Method | Testing Condition | Injection Molding Typical Value | 3D Printing X-Y Axis Typical Value | 3D Printing Z Axis Typical Value | Unit |
Glass Transition Temperature | DSC | 10℃/min | 81.6 | ℃ | ||
Decomposition Temperature | TGA | 20℃/min | 387.5 | ℃ | ||
Heat Distortion Temperature | ISO 75 | 0.45MPa | 71.8 | 74.8 | 72.9 | ℃ |
Heat Distortion Temperature | ISO 75 | 1.8MPa | 63.8 | 69.8 | 67.6 | ℃ |
Vicat Softening Temperature | ISO 306 | 50℃/10N | 79.7 | 78.0 | 77.3 | ℃ |
Recommended 3D Printing Parameters
*Based on 0.4 mm nozzle. Printing conditions may vary with different nozzle diameters
Printing Temperature | 240 – 260 (℃) |
Bed Temperature | 70 - 80 (℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 0 - 10% |
Printing Speed | 30 – 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
3DPrinting Actual Parameters
*All specimens must be left at room temperature for 24 hours before testing. The parameters are based on the Bambulab PES 3D Printer.
Printing Temperature | 250 (℃) |
Bed Temperature | 80 (℃) |
Wall Layers | 2 Layers |
Top and Bottom Layers | 4 Layers |
Infill | 100% |
Ambient Temperature | 25℃ |
Cooling Fan | 10% |
Printing Speed | 50 (mm/s) |
Nozzle Diameter | 0.4 mm |
