PETG is a glycol modified version of polyethylene terephthalate (PET), commonly used in water bottle manufacturing. Filaments that are made from PETG are widely applied in 3D Printing due to their special properties and easy-of-processing. It is a kind of ideal Printing Material with practical application value.
Diameter: 1.75mm/2.85mm Weight of each roll:1kg/2.5kg
PETG Printing Filaments are commonly used in 3D Printing. As a new type of 3D Printing Material, PETG shares advantages of PLA and ABS, whose printing products have good glossiness, high strength, low warping, smooth surfaces. What’s more, the products are not easy to break and almost no odor during printing.
It is important to note that each material has its unique Features and Application scopes, so users are advised to consider comprehensively based on specific requirements and printer models when choose to use it. Meanwhile, an appropriate settings and adjustment still need to be made according to Printer types and individual needs for the best printing effect when you use PETG Filaments.
PETG has a higher strength and toughness than PLA, so its printing objects are more durable.
Better Heat Resistance:
PETG can endure a higher temperature, so it has advantages in applications where there needs high-temperature resistance.
Transparency:
PETG can produce transparent or semi-transparent products which are suitable for projects that need transparent parts.
Chemical Resistance:
PETG has a good tolerance to some chemicals, making it suitable for some special environments or applications that require exposure to chemical substances.
Low Temperature Printing:
Compared with other materials, PETG can be printed at lower temperatures where heat damages to printers or printer parts can be reduced.
Low Shrinkage Rate:
PETG has a lower shrinkage rate, helping maintain dimensional accuracy of printing objects.
Food Grade Safety:
Some PETG materials can be used in food contact applications, such as printing food containers or packaging.
Colors can be Customized for your requirement
Bright Red
Brass
Cinnabar Red
White
Black
Light Gray
Bright Red
Brass
Cinnabar Red
White
Black
Light Gray
Metallic Silver
Champagne Gold
Glitter Silver
Bronze
Lemon Green
Yellow
Metallic Silver
Champagne Gold
Glitter Silver
Bronze
Lemon Green
Yellow
Lake Blue
Orange
Cherry Blossom Pink
Transparent
Skin Color
Mint Green
Lake Blue
Orange
Cherry Blossom Pink
Transparent
Skin Color
Mint Green
Violet
Magenta
Green
Army Green
Black Nickel
Beige
Violet
Magenta
Green
Army Green
Black Nickel
Beige
Olive Green
Klein Blue
Red Wine
Coffee Color
Dark Gray
Amber Gold
Olive Green
Klein Blue
Red Wine
Coffee Color
Dark Gray
Amber Gold
Red Copper
Marble
Red Copper
Marble
{"type": "4"}
Printing Parameters
Description
Data
Desciption
Data
Nozzle Temperature
240—280℃
Heated Distortion Temperature
73.2℃
Nozzle Diameter
≥0.4 mm
Printing Platform
Add glue according to Materials
Printing Speed
40--300 mm/s
Cooling Fan
On
Suitable for all FDM 3D Printers / 3D Printing Machines
Physical Properties
Properties
Testing method
Value
Density
ISO 1183-1
1.27g/cm3
Melt Flow Index
ISO 1133
8-10g/10min
Thermal Performance
Properties
Testing Method
Value
Heat Distortion Temperature
ISO 72
0.45Mpa
1.80Mpa
73.2℃
63.9℃
Mechanical Performance
Printing Direction
Testing Standard
Data
Tensile Strength
ISO 527
54.49Mpa
Elongation at break
ISO 527
3.18%
Flexural Strength
ISO 178
73.82Mpa
Flexural Modulus
ISO 178
2048Mpa
Charpy Impact Strength with Notched
ISO 179
1.59KJ/㎡
Charpy Impact Strength without Notched
ISO 179
NB
Printing Parameters
Description
Data
Desciption
Data
Nozzle Temperature
240—280℃
Heated Distortion Temperature
73.2℃
Nozzle Diameter
≥0.4 mm
Printing Platform
Add glue according to Materials
Printing Speed
40--300 mm/s
Cooling Fan
On
Suitable for all FDM 3D Printers / 3D Printing Machines
Jiangyin Longshan Synthetic Materials Co., Ltd. is a modified plastics company integrating R&D, production and sales, specializing in the development of medium and high-end modified materials.
