The 1.75mm diameter is available in nearly all filament materials including:
PLA: Easy to print and eco-friendly, ideal for beginners.
PETG: Strong, flexible, and resistant to chemicals, perfect for functional parts.
ABS: High strength and temperature resistance, although more challenging to print.
TPU: A flexible filament for prints that require elasticity.
Nylon, Carbon-Fiber Filled Filaments, and more: Advanced materials for industrial-grade projects.
Benefits of 1.75mm Filament 3D Printers:
Better Flow Control: The thinner filament provides more precise extrusion control, allowing for better-quality prints, especially in detailed projects. The extruder can more easily push smaller volumes of melted plastic through the nozzle, leading to smoother layers.
Energy Efficiency: With less material passing through the hotend at a time, 1.75mm filament heats up faster than thicker filaments, leading to potentially quicker printing and less energy consumption.
Greater Market Availability: The 1.75mm filament size is the most widely available filament on the market, ensuring you have a vast array of materials, brands, and colors to choose from.
Faster Printing for Small Nozzles:If you are using a small nozzle size (like 0.2mm or 0.3mm), the smaller diameter filament can result in more consistent printing and reduce clogging risks compared to thicker filaments.
Welcome to consult, if you want to know more about 1.75mm Filament 3d Printer From Aliz 3D Printing Filament !
The 1.75mm diameter is available in nearly all filament materials including:
PLA: Easy to print and eco-friendly, ideal for beginners.
PETG: Strong, flexible, and resistant to chemicals, perfect for functional parts.
ABS: High strength and temperature resistance, although more challenging to print.
TPU: A flexible filament for prints that require elasticity.
Nylon, Carbon-Fiber Filled Filaments, and more: Advanced materials for industrial-grade projects.
Benefits of 1.75mm Filament 3D Printers:
Better Flow Control: The thinner filament provides more precise extrusion control, allowing for better-quality prints, especially in detailed projects. The extruder can more easily push smaller volumes of melted plastic through the nozzle, leading to smoother layers.
Energy Efficiency: With less material passing through the hotend at a time, 1.75mm filament heats up faster than thicker filaments, leading to potentially quicker printing and less energy consumption.
Greater Market Availability: The 1.75mm filament size is the most widely available filament on the market, ensuring you have a vast array of materials, brands, and colors to choose from.
Faster Printing for Small Nozzles:If you are using a small nozzle size (like 0.2mm or 0.3mm), the smaller diameter filament can result in more consistent printing and reduce clogging risks compared to thicker filaments.
Welcome to consult, if you want to know more about 1.75mm Filament 3d Printer From Aliz 3D Printing Filament !
Printing Parameters
Description | Data | Desciption | Data |
Nozzle Temperature | 204—280℃ | Heated bed Temperature | 70℃ |
Nozzle Diameter | ≥0.4 mm | Printing Platform | Add glue according to Materials |
Printing Speed | 40--300 mm/s | Cooling Fan | On |
Suitable for all FDM 3D Printers / 3D Printing Machines |
Physical Properties
Properties | Testing method | Value |
Density | ISO 1183-1 | 1.27g/cm3 |
Melt Flow Index | ISO 1133 | 8-10g/10min |
Thermal Performance
Properties | Testing Method | Value | |
Heat Distortion Temperature | ISO 72 | 0.45Mpa 1.80Mpa | 73.2℃ 63.9℃ |
Mechanical Performance
Printing Direction | Testing Standard | Data |
Tensile Strength | ISO 527 | 54.49Mpa |
Elongation at break | ISO 527 | 3.18% |
Flexural Strength | ISO 178 | 73.82Mpa |
Flexural Modulus | ISO 178 | 2048Mpa |
Charpy Impact Strength with Notched | ISO 179 | 1.59KJ/㎡ |
Charpy Impact Strength without Notched | ISO 179 | NB |
Printing Parameters
Description | Data | Desciption | Data |
Nozzle Temperature | 204—280℃ | Heated bed Temperature | 70℃ |
Nozzle Diameter | ≥0.4 mm | Printing Platform | Add glue according to Materials |
Printing Speed | 40--300 mm/s | Cooling Fan | On |
Suitable for all FDM 3D Printers / 3D Printing Machines |
Physical Properties
Properties | Testing method | Value |
Density | ISO 1183-1 | 1.27g/cm3 |
Melt Flow Index | ISO 1133 | 8-10g/10min |
Thermal Performance
Properties | Testing Method | Value | |
Heat Distortion Temperature | ISO 72 | 0.45Mpa 1.80Mpa | 73.2℃ 63.9℃ |
Mechanical Performance
Printing Direction | Testing Standard | Data |
Tensile Strength | ISO 527 | 54.49Mpa |
Elongation at break | ISO 527 | 3.18% |
Flexural Strength | ISO 178 | 73.82Mpa |
Flexural Modulus | ISO 178 | 2048Mpa |
Charpy Impact Strength with Notched | ISO 179 | 1.59KJ/㎡ |
Charpy Impact Strength without Notched | ISO 179 | NB |
