Printing Parameters
Description | Data | Desciption | Data |
Nozzle Temperature | 250—280℃ | Heated bed Temperature | 80-100℃ |
Printing Platform Material | Soft Magnetic Sticker | Printing Platform Surface Treatment | Glue |
Bottom Value Sparation Distance | 0.2-0.8 | Withdrawal Distance | - |
Environment Temperature | - | Withdrawal Speed | - |
Recommended Support Material | - | Drying Temperature | - |
Printing Speed | 40--200 mm/s | Cooling Fan | 0-80% |
Suitable for all FDM 3D Printers / 3D Printing Machines |
Physical Properties
Properties | Testing method | Value |
Density | ISO 1183-1 | 1.07g/cm3 |
Melt Flow Index | ISO1133 | 23g/10min |
Flame Properties
Properties | Testing method | Value |
Flame Retardance | - | - |
Thermal Performance
Properties | Testing Method | Value | |
Glass Transsition | - | - | |
Melting Temperature | - | - | |
Decomposition Temperature | - | - | |
Cofficient of Thermal Expansion | - | - | |
Shrinking Percentage | - | - | |
Vicat Softening Temperature | ISO 306 | 106℃ | |
Heat Distortion Temperature | ISO75 | 0.45Mpa/85℃ |
Mechanical Performance
Printing Direction | Testing Standard | Data |
Tensile Strength | ISO527 | 40.5Mpa |
Elongation at break | ISO527 | 3% |
Flexural Strength | ISO178 | 55Mpa |
Flexural Modulus | ISO178 | 1800Mpa |
Impact Strength with Notched | ISO179 | 21J/㎡ |
Impact Strength without Notched | ISO179 | 41.0±2.3J/㎡ |
