Printing Parameters
| Description | Data | Desciption | Data |
| Nozzle Temperature | 220—250℃ | Heated bed temperature | 60—80℃ |
| Printing Platform Material | - | Printing Platform Surface Treatment | Add glue according to material |
| Bottom Value Sparation Distance | - | Withdrawal Distance | - |
| Environment Temperature | - | Withdrawal Speed | - |
| Recommended Support Material | - | Drying Temperature | - |
| Printing Speed | 40--200 mm/s | Cooling Fan | Open |
| -Almost suitable for all FDM 3D Printers/ 3D Printing Machines | |||
Physical Properties
Properties | Testing method | Value |
Density | ISO 1183-1 | 1.22g/cm3 |
| Melt Flow Index | ISO1133 | 36.5±2.6g/10min |
Thermal Performance
Properties | Testing Method | Value | |
| Glass Transsition | ISO 11357 | -℃ | |
| Melting Temperature | ISO 11357 | 183℃ | |
| Decomposition Temperature | / | -℃ | |
| Vicat Softening Temperature | ISO 306 | 140℃ | |
Heat Distortion Temperature | ISO72 | 0.45Mpa/90℃ | |
Mechanical Performance
Printing Direction | Testing Standard | Data |
Tensile Strength | ISO527 | 30.5Mpa |
Elongation at break | ISO527 | 440% |
Flexural Strength | ISO178 | -Mpa |
Flexural Modulus | ISO178 | -Mpa |
Impact Strength with Notched | ISO179 | -KJ/㎡ |
Impact Strength without Notched | ISO179 | -KJ/㎡ |
