PA-CF General Version, Carbon Fibers content of 15%
PA-CF 3D printing filament is a composite material made from nylon (PA) reinforced with carbon fibers (CF). This filament offers high strength, heat resistance, and excellent stiffness, making it ideal for printing lightweight, durable parts. It's commonly used for industrial applications like automotive components, tools, and mechanical parts that need to withstand heavy stress.

We are the leading manufacturer of PA-CF 3D printing filaments in China. Our carbon fiber reinforced polyamide filaments meet international quality standards and industrial performance requirements. For your manufacturing needs, we provide comprehensive material solutions and technical support. Contact us today!

Diameter:
1.75mm/2.85mm
Weight of each roll:
1kg/2kg
Availability:
Inquire Add to Basket

Our PA-CF 3D printer filament represents advanced engineering-grade material technology, combining superior mechanical strength, exceptional durability, and outstanding thermal resistance. This carbon-fiber reinforced nylon formulation elevates traditional nylon properties to new performance levels, delivering enhanced wear resistance and minimal moisture absorption.

This innovative filament offers simplified printing requirements - no heated chamber necessary while maintaining high-temperature printing capability at 250°C and above. With a heat deflection temperature exceeding 180°C, this professional-grade material meets demanding industrial applications across multiple sectors. The material's engineered composition ensures reliable performance in functional prototypes and end-use parts.
Aliz PA-CF
Advantages:

PA-CF Nylon FDM Printing Filament has advantages over other Nylon Materials in high strength, high toughness, high wear-resistance, high temperature resistance, excellent chemical resistance and low absorption of humidity, which make it an ideal choice for some product manufacturing, such as automotive parts, aerospace parts, medical apparatus and instruments.

*Self-lubrication and wear resistance make it suitable for gears printing.
*High toughness and impact resistance make it suitable for durable parts.
*High temperature resistance with distortion temperature up to 170℃.


Our PA-CF carbon fiber reinforced 3D printer filament delivers professional-grade engineering performance. This high-strength nylon composite operates at 260-290°C nozzle temperature, offering industrial-level mechanical properties with a tensile strength of 103.35MPa and heat resistance up to 218°C.


The material features enhanced stability with 1.19g/cm³ density and optimized flow characteristics, making it ideal for manufacturing functional parts. Its superior mechanical specifications include 146.1MPa flexural strength and exceptional impact resistance, perfect for demanding industrial applications and engineering prototypes.


This advanced filament supports print speeds of 40-300mm/s, requiring minimal post-processing while maintaining dimensional accuracy. Each batch undergoes ISO standard testing, ensuring consistent quality for professional manufacturing requirements.


Printing Parameters

Description Data Desciption Data
Nozzle Temperature 260—290℃  Heated bed Temperature 80℃
Nozzle Diameter ≥0.4 mm Printing Platform Add glue according to Materials
Printing Speed   40-300 mm/s Cooling fan Not required
Suitable for all FDM 3D Printers / 3D Printing Machines


Physical Properties

Properties

Testing method

Value

Density

ISO 1183-1

1.19g/cm3

Melt Flow Index

ISO 1133

5.2g/10min


Thermal Performance

Properties

Testing Method

Value
Glass Transition ISO 11357 148℃
Melting Temperature ISO 11357
 218℃
Decomposition Temperature / 457℃
Vicat Softening Temperature ISO 306
 /

Heat Distortion Temperature

ISO 72

0.45Mpa

1.80Mpa

167.2℃

75.3℃


Mechanical Performance


Printing Direction

Testing Standard

Data

Tensile Strength

ISO 527

103.35Mpa

Elongation at break

ISO 527

1.94%

Flexural Strength

ISO 178

146.1Mpa

Flexural Modulus

ISO 178

6702Mpa

Charpy Impact Strength with Notched

ISO 179

5.66KJ/㎡

Charpy Impact Strength without Notched

ISO 179

28.57KJ/㎡
